Universal Machine Fit
Machine-Compatible Molds for Kurtz, Erlenbach & Fangyuan
Every mold is verified against your machine platen layout before machining starts. No surprise fitment issues at commissioning.
Request DFM Review4 Brands
Machine Compatibility
15-Point
DFM Machine Check
Staubli
Standard Fittings
25–40 Days
Lead Time
Verified Fit Before a Single Cut Is Made
Fitment failures at commissioning cost time and money. Our 15-point DFM machine check maps platen bolt patterns, steam port positions, fill gun geometry, and mold weight limits against your exact machine model before machining begins.
We hold certified platen drawings for Kurtz, Erlenbach, Fangyuan, and Teubert machines. If your machine is not on the list, send us the platen drawing and we add it to our database at no charge.
- ✓ Kurtz, Erlenbach, Fangyuan, and Teubert platen drawings on file
- ✓ Staubli quick-connect fittings on all steam/water/air lines
- ✓ Platen bolt pattern verified before mold design is finalized
- ✓ Machine interface dimensions annotated on final drawing
- ✓ No adapter plates, no machine-side modifications required
Mold Details
Kurtz machine interface verification
Platen dimension mapping
Steam port layout verification
Technical Specifications
| Compatible brands | Kurtz · Erlenbach · Fangyuan · Teubert · Any brand with spec sheet |
| DFM check points | 15-point machine interface verification |
| Fittings standard | Staubli quick-connect (steam / water / air) |
| Platen mapping | Bolt pattern, T-slot, steam port, fill gun geometry |
| Lead time | 25–40 days from approved DFM |
| Documentation | Machine-interface drawing included in 5-document package |
5 Documents Included with Every Mold
- 1 DFM Analysis Report — draft angles, wall thickness, fill-gun layout
- 2 Shrinkage Calculation Sheet — EPP grade vs. compensated dimension table
- 3 Steam Port Mapping — diagram of all inlet, outlet, and drain positions
- 4 Test-Shot Data Sheet — first-article dimensions vs. nominal, signed off
- 5 Final Inspection Report — CMM measurement report with traceable calibration
Have a machine compatibility question?
Send your machine model number. We check our library and respond within 24 hours.
Request Free DFM Review
